| General Information | |
|---|---|
| Operating Temperature | -40 °C up to +85 °C |
| Material Properties | |
|---|---|
| Frame Material | PA66 |
| Frame Flammability Rating | UL94 V-0 |
| Frame Color | Grey |
| Actuator Material | PA66 |
| Actuator Flammability Rating | UL94 V-0 |
| Actuator Color | Red |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Terminal Material | Copper Alloy |
| Terminal Plating | Gold |
| Electrical Properties | |
|---|---|
| IR | 500 mA |
| VR | 12 V (DC) |
| Contact Resistance Initial | 30 mΩ |
| RISO | 10000 MΩ |
| Withstanding Voltage | 500 V (AC) |
| Mechanical Properties | |
|---|---|
| Electrical Life | 2000 Steps |
| Connection Type | Opposite Side Connection |
Products
| Order Code | Datasheet | Downloads | Operation Force (Value) (g) | Schematic | Packaging | Design Kit | Demoboard | Samples | |
|---|---|---|---|---|---|---|---|---|---|
 | 450301014042 | SPEC | 5 files | 800 | SPDT | Bulk | 499001 | 9999003 |
| Order Code | Datasheet | |
|---|---|---|
| 450301014042 | SPEC |
| Samples |
|---|
| Order Code | Datasheet | Downloads | Operation Force (Value) (g) | Schematic | Packaging | Design Kit | Demoboard | Samples |
|---|
