WR-PHD 2.54 mm THT Angled Pin Header

Characteristics

Reference Designs

RD006 3 W Dual-output isolated auxiliary supply for communication interfaces and measurement systems

Article Properties
Pins	2; 3; 4; 5; 6; 7; 8; 9; 10; 12; 14; 15; 16; 18; 22; 32; 34; 36; 40

Material Properties
Insulator Material	PA6T
Insulator Flammability Rating	UL94 V-0
Contact Material	Copper Alloy
Contact Plating	Gold
Contact Type	Stamped

General Information
Operating Temperature	-40 °C up to +105 °C
Pitch	2.54 mm
Durability	25 Mating cycles
Rows	Single
Gender	Pin Header
Type	Angled

Electrical Properties
Withstanding Voltage	500 V (AC)
Contact Resistance	20 mΩ
R_ISO	1000 MΩ

Certification
UL Approval	E323964

Packaging Properties
Packaging	Bag

Products

Order Code	Datasheet	Downloads	Pins	Rows	Gender	Type	I_R (A)	Packaging	Design Kit	Samples
61300211021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300211021_1 (rev1).pdf \| 22.8 KB IGS 61300211021 (rev1).igs \| 285.3 KB STP 61300211021 (rev1).stp \| 112.8 KB	2	Single	Pin Header	Angled	3	Bag	–
61300311021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300311021_1 (rev1).pdf \| 26.8 KB IGS 61300311021 (rev1).igs \| 373.5 KB STP 61300311021 (rev1).stp \| 146.6 KB	3	Single	Pin Header	Angled	3	Bag	–
61300411021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300411021_1 (rev1).pdf \| 30.9 KB IGS 61300411021 (rev1).igs \| 466.9 KB STP 61300411021 (rev1).stp \| 180.6 KB	4	Single	Pin Header	Angled	3	Bag	–
61300511021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300511021_1 (rev1).pdf \| 36.3 KB IGS 61300511021 (rev1).igs \| 558.1 KB STP 61300511021 (rev1).stp \| 214.4 KB	5	Single	Pin Header	Angled	3	Bag	–
61300611021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300611021_1 (rev1).pdf \| 41.4 KB IGS 61300611021 (rev1).iges \| 649.2 KB STP 61300611021 (rev1).stp \| 252.4 KB	6	Single	Pin Header	Angled	3	Bag	–
61300711021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300711021_1 (rev1).pdf \| 45.8 KB IGS 61300711021 (rev1).igs \| 733.9 KB STP 61300711021 (rev1).stp \| 282.2 KB	7	Single	Pin Header	Angled	3	Bag	–
61300811021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300811021_1 (rev1).pdf \| 50.3 KB IGS 61300811021 (rev1).iges \| 829 KB STP 61300811021 (rev1).stp \| 321 KB	8	Single	Pin Header	Angled	3	Bag	613001
61300911021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61300911021_1 (rev1).pdf \| 54.7 KB IGS 61300911021 (rev1).iges \| 922.2 KB STP 61300911021 (rev1).stp \| 355.2 KB	9	Single	Pin Header	Angled	3	Bag	–
61301011021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61301011021_1 (rev1).pdf \| 59.1 KB IGS 61301011021 (rev1).igs \| 1011.3 KB STP 61301011021 (rev1).stp \| 384.1 KB	10	Single	Pin Header	Angled	3	Bag	613001
61301211021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61301211021_1 (rev1).pdf \| 68.1 KB IGS 61301211021 (rev1).igs \| 1.2 MB STP 61301211021 (rev1).stp \| 451.9 KB	12	Single	Pin Header	Angled	3	Bag	–
61301411021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61301411021_1 (rev1).pdf \| 77.1 KB IGS 61301411021 (rev1).igs \| 1.3 MB STP 61301411021 (rev1).stp \| 519.7 KB	14	Single	Pin Header	Angled	3	Bag	–
61301511021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 3D_61301511021 (rev1).pdf \| 84.9 KB IGS IGS_61301511021 (rev1).igs \| 1.4 MB STP STP_61301511021 (rev1).stp \| 326.7 KB	15	–	–	–	3	Bag	–
61301611021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61301611021_1 (rev1).pdf \| 86.2 KB IGS 61301611021 (rev1).iges \| 1.5 MB STP 61301611021 (rev1).stp \| 595.8 KB	16	Single	Pin Header	Angled	3	Bag	–
61301811021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61301811021_1 (rev1).pdf \| 95.2 KB IGS 61301811021 (rev1).iges \| 1.7 MB STP 61301811021 (rev1).stp \| 666.7 KB	18	Single	Pin Header	Angled	3	Bag	613001
61302211021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61302211021_1 (rev1).pdf \| 113.3 KB IGS 61302211021 (rev1).iges \| 2.1 MB STP 61302211021 (rev1).stp \| 808.7 KB	22	Single	Pin Header	Angled	3	Bag	–
61303211021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61303211021_1 (rev1).pdf \| 159.2 KB IGS 61303211021 (rev1).igs \| 3 MB STP 61303211021 (rev1).stp \| 1.1 MB	32	Single	Pin Header	Angled	3	Bag	–
61303411021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61303411021_1 (rev1).pdf \| 168.4 KB IGS 61303411021 (rev1).igs \| 3.2 MB STP 61303411021 (rev1).stp \| 1.2 MB	34	Single	Pin Header	Angled	3	Bag	–
61303611021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61303611021_1 (rev1).pdf \| 177.6 KB IGS 61303611021 (rev1).igs \| 3.4 MB STP 61303611021 (rev1).stp \| 1.3 MB	36	Single	Pin Header	Angled	3	Bag	–
61304011021	SPEC	6 files EDA models: Components ZIP ALT Altium_WR-PHD (rev24a).IntLib \| 34.1 MB CDS Cadence_WR-PHD (rev24c).zip \| 63.9 MB EAG Eagle_WR-PHD (rev24b).lbr \| 5.2 MB CAD files ZIP 3D 61304011021_1 (rev1).pdf \| 195.9 KB IGS 61304011021 (rev1).iges \| 3.8 MB STP 61304011021 (rev1).stp \| 1.4 MB	40	Single	Pin Header	Angled	3	Bag	–
