Calypso IoT Design Kit

Characteristics

Design Kit for prototyping Sensor-to-Cloud IoT applications
Monitor temperature, absolute pressure, relative humidity and 3-axis acceleration
Plug-and-Play secure connectivity to Azure IoT central
Design Kit in Adafruit Feather formfactor
Easy to expand with our WE FeatherWings and hundreds of already existing boards with the Feather form factor
Arduino (C/C++) drivers and code examples available on GitHub

Applications

Rapid prototype development for IoT applications
Easy to use platform for learning, experimenting and prototyping IoT applications
Remote monitoring and control
Collect sensor data, store, visualize and analyze the data
Plug-and-Play secure cloud connectivity

IoT Plug-and-Play! IoT connectivity simplified.

Kick start your IoT Project. Build your secure End-to-End IoT solution prototype rapidly using the Calypso IoT design kit and Microsoft’s IoT central.

Explore Azure certified device catalog

Products

Order Code	Datasheet	Manual	Downloads	Status	Description	Offer
2610059035001	–	PDF	–	Active i\| Production is active. Expected lifetime: >10 years.	Calypso IoT Design Kit

Order Code	Datasheet
2610059035001	–

Offer

Order Code	Datasheet	Manual	Downloads	Status	Description	Offer

Software Downloads

Wireless Connectivity SDK

The aim of the Wireless Connectivity Software Development Kit (SDK) is to minimize the effort required on customer side to enable his host MCU to communicate with Würth Elektronik eiSos radio modules. It contains the implementation of all available commands in pure C-code. In order to integrate any Würth Elektronik eiSos wireless module, the user has to simply port the corresponding C-code to his host processor. This significantly reduces the time needed for developing the software interface to the radio module.

Download now on GitHub

Calypso FOTA

MCalypso Firmware Over The Air (FOTA) - This is the firmware update package for the Calypso Wi-Fi Module. The Calypso Wi-Fi Module offers secure Over-the-Air firmware updates to enable easy update of the firmware in the field. The update package includes the module firmware, service pack, root certificate catalogue and the files for the on-board web server. It is always recommended to use the latest version of the firmware. Please refer to the chapter on “Firmware Update” of the Calypso User Manual for instructions of updating the firmware on the Calypso Wi-Fi module.

Download now

Certificate Generator Tool

In order to securely, connect devices to any cloud platform, X.509 certificate based authentication is used. This method requires creation of certificates for every device. In order to enable easy prototyping, Würth Elektronik eiSos’s Certificate generator tool can be used. This tool creates all the certificates necessary to get started. It is important to note that the files generated by this tool are for evaluation purposes only.

Due to current export legal restrictions, we are required to control the provision of software. To download the software, please contact our technical support or your local sales representative directly. Thank you for your understanding.

IoT Plug-and-Play! IoT connectivity simplified.

Rapid prototyping for IoT

The Calypso IoT Design Kit is a kit of stackable evaluation board with pre-installed firmware that enables easy creation and evaluation of a secure End-to-End IoT solution using Microsoft’s Azure IoT central.
This design kit offers a reliable hardware platform for rapid prototyping using FeatherWings, a set of development boards which are open source and fully compatible with the Feather form factor from Adafruit.
Being “IoT Plug-and-Play” certified this kit enables seamless Device-to-Cloud integration into Microsoft Azure.
Supercharge your IoT prototyping with the Design Kit and Microsoft’s IoT central cloud platform.

Stacking boards ideal for prototyping

WE FeatherWings

Würth Elektronik eiSos presents a range of FeatherWing development boards that are open source and fully compatible with the Feather form factor. Through these development boards, WE brings a range of wireless connectivity modules, sensors and power modules to the Feather ecosystem.

Adafruit Feather is a complete line of development boards from Adafruit and other developers that are both standalone and stackable. They're able to be powered by LiPo batteries for On-the-Go use or by their micro-USB plugs for stationary projects.

Feathers are flexible, portable and as light as their namesake. FeatherWings are stacking boards and add functionality and room for prototyping. At its core, the Adafruit Feather is a complete ecosystem of products - and the best way to get your project flying.

Supercharge your prototyping for easy and fast solution testing. Start by checking our quick start section.

Boards

IC LED FeatherWing (150015)

Boards

5V power supply via USB-C connection
Easy connection to sensors and bluetooh modules
Framerate up to 150 Hz, arbitrarily adjustable
Usable with 1.8V logic controllers outside FW-standard

Go to board

Calypso IoT Design Kit (2610059035001)

Boards

Design Kit for prototyping Sensor-to-Cloud IoT applications
Monitor temperature, absolute pressure, relative humidity and 3-axis acceleration
Plug-and-Play secure connectivity to Azure IoT central

Go to board

Sensor FeatherWing (2501000201291)

Temperature
Humidity
Acceleration
Absolute pressure
Sparfun QWIIC compatible to easily add hundreds of extension boards

Go to board

MagI³C Power FeatherWing (2601157100001)

5 V USB connection
Industrial input voltage rails of 9 V, 12 V, 15 V, 18 V and 24 V with maximum nominal input voltage of 36 V

Go to board

Serial Bridge FeatherWing (2601167101001)

Boards

Standard DSUB9 connector
3V3 logic level UART interface on the Feather pin header
RS232 with and without flow control
Full and half duplex RS485
Double throw slider to switch between RS232 and RS485

Go to board

SensorBLE FeatherWing Kit (2611187024001)

Boards

Monitor temperature, absolute pressure, relative humidity and 3-axis acceleration
Universal connectivity to any smart device using Bluetooth® LE 5.1
WE-SensorBLE app for data visualization on Android and iOSAdrastea Cellular FeatherWing

Go to board

Adrastea Cellular FeatherWing (2615039336001)

Boards

The FeatherWing kit includes one Adrastea-I FeatherWing board with the LTE-M / NB-IoT Adrastea-I module, the external LTE antenna, the external GNSS antenna and USB cable.
Flexible mode selection between LTE-M and NB-IoT
3GPP release 13 compliant
Integrated GNSS (supports GPS & GLONASS)
Integrated user MCU (ARM Cortex-M4, 1 MB flash memory, 256 KB RAM)
Output power class 3 (23 dBm)
Supports 3GPP TS27.005, 27.007 and Würth Elektronik enhanced AT commands
Protocols: IPv4/IPv6, TCP/UDP, HTTP/HTTPS, TLS/DTLS, MQTT, LWM2M
LTE-M supported bands: B2/B3/B4/B5/B8/B12/B20/B25/B26/B28
NB-IoT supported bands: B3/B5/B8/B20/B28

Go to board

Thyone-I Wireless FeatherWing (2611059021001)
