| General Information | |
|---|---|
| Operating Temperature | -25 °C up to +85 °C |
| Gender | Socket |
| Type | Push & Pull |
| Material Properties | |
|---|---|
| Insulator Material | LCP |
| Insulator Flammability Rating | UL94 V-0 |
| Insulator Color | Black |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Flash |
| Contact Type | Stamped |
| Shielding Material | Stainless Steel |
| Shielding Plating | Nickel (Ni) |
| Electrical Properties | |
|---|---|
| Working Voltage | 15 V (AC) |
| Withstanding Voltage | 500 V (AC) |
| Contact Resistance | 100 mΩ |
Products
| Order Code | Datasheet | Downloads | Status | Pins (Value) (pcs) | Gender | Type | Mount | Operating Temperature | Working Voltage (V (AC)) | Design Kit | Samples |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 693043020611 | SPEC | 6 files | Active i| Production is active. Expected lifetime: >10 years. | 6 | Socket | Push & Pull | SMT | -25 °C up to +85 °C | 15 | 614001 |
| Order Code | Datasheet |
|---|---|
| 693043020611 | SPEC |
| Samples |
|---|
| Order Code | Datasheet | Downloads | Status | Pins (Value) (pcs) | Gender | Type | Mount | Operating Temperature | Working Voltage (V (AC)) | Design Kit | Samples |
|---|
