General Information | |
---|---|
Operating Temperature | -40 °C up to +105 °C |
Compliance | RoHS |
Pitch | 3.5 mm |
Material Properties | |
---|---|
Insulator Material | PA66 |
Insulator Flammability Rating | UL94 V-0 |
Contact Material | Brass |
Contact Plating | Tin |
Electrical Properties | |
---|---|
IR | 10 A; 10.5 A |
IR | 10 A |
IR | 10.5 A |
Working Voltage | 300 V (AC) |
Working Voltage [cULus] | 300 V (AC) |
Working Voltage [VDE] | 300 V (AC) |
Withstanding Voltage [cULus] | 1600 V (AC) |
Withstanding Voltage [VDE] | 2500 V (AC) |
RC | 20 mΩ |
RC | 20 mΩ |
Certification | |
---|---|
cULus Approval | E315414 |
VDE Approval | 40023195 |
Application Notes
Products
Order Code | Datasheet | Downloads | Pins (Value) (pcs) | Application | PCB/Cable/Panel | Modularity | Type | Samples |
---|---|---|---|---|---|---|---|---|
691323100002 | SPEC | 6 files | 2 | Pluggable | PCB | No | Vertical | |
691323100003 | SPEC | 6 files | 3 | Pluggable | PCB | No | Vertical | |
691323100004 | SPEC | 6 files | 4 | Pluggable | PCB | No | Vertical | |
691323100005 | SPEC | 6 files | 5 | Pluggable | PCB | No | Vertical | |
691323100006 | SPEC | 6 files | 6 | Pluggable | PCB | No | Vertical | |
691323100007 | SPEC | 6 files | 7 | Pluggable | PCB | No | Vertical | |
691323100008 | SPEC | 6 files | 8 | Pluggable | PCB | No | Vertical | |
691323100012 | SPEC | 6 files | 12 | Pluggable | PCB | No | Vertical |
