| Size | Dimensions | L (mm) | W (mm) | H (mm) | Mount | |
|---|---|---|---|---|---|---|
| 2010 | 2 | 1.6 | 1 | SMT | ||
| 2512 | 2.5 | 2 | 1.2 | SMT | ||
| 3015 | 3 | 3 | 1.5 | SMT | ||
| 4012 | 4 | 4 | 1.2 | SMT | ||
| 4018 | 4 | 4 | 1.8 | SMT | ||
| 4025 | 4 | 4 | 2.5 | SMT | ||
| 5020 | 5 | 5 | 2 | SMT | ||
| 5040 | 5 | 5 | 4 | SMT | ||
| 6028 | 6 | 6 | 2.8 | SMT | ||
| 6045 | 6 | 6 | 4.5 | SMT | ||
| 8040 | 8 | 8 | 4.2 | SMT | ||
| 8065 | 8 | 8 | 6.5 | SMT |
LTSpice files
Characteristics
- Compact design Power Inductor
- 1.7 times more current than compared to an unshielded version
- Robust construction
- Low RDC
- Magnetically shielded by use of a magnetic resin
- Operating temperature: -40°C to +125°C
Reference Designs
- RD022 GB PoE+-Ethernet-USB“ adapter for industrial use with an EMC perspective
Applications
- Integrated DC/DC Converters
- Switching controllers which require high efficiency
- Portable power (PDA, Smartphones, Digital Cameras, TVs, LCD etc.)
- Embedded Laptops and PCs
- Big sizes can be used in shock resisting circuits
Products
All
2010
2512
3015
4012
4018
4025
5020
5040
6028
6045
8040
8065
| Order Code | Datasheet | Simulation | Downloads | Status | L (µH) | IR (A) | ISAT (A) | RDC (mΩ) | fres (MHz) | Design Kit | Samples |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 744040240016 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.16 | 3.7 | 7 | 16 | 644 | 7440402 | ||
| 744040200016 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.16 | 3 | 4.9 | 25 | 540 | 7440402 | ||
| 744040420033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.33 | 4.5 | 7.6 | 13 | 326 | – | ||
| 744040200033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.33 | 2.5 | 3.4 | 34 | 363 | – | ||
| 744040240047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.47 | 2.6 | 5 | 32 | 231 | 7440402 | ||
| 744040320047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.47 | 3 | 4 | 18 | 304 | 7440402 | ||
| 744040410047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.47 | 3.25 | 4.25 | 28 | 274 | 7440405 | ||
| 744040520047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.47 | 4.9 | 8.5 | 13.9 | 252 | 7440405 | ||
| 744040640047 | SPEC | 8 files | NRND i| Production is active. Product is not recommended for new design. Expected lifetime: 2-5 years. | 0.47 | 8 | 16 | 6 | 235 | – | ||
| 744040200047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.47 | 2.1 | 2.8 | 47 | 293 | 7440402 | ||
| 744040240068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.68 | 2.5 | 3.5 | 35 | 176 | 7440402 | ||
| 744040640068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.68 | 7.2 | 12 | 7 | 169 | – | ||
| 744040200068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.68 | 1.8 | 2.4 | 64 | 196 | – | ||
| 744040630082 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 0.82 | 6 | 9.5 | 10 | 144 | – | ||
| 74404024010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 2.3 | 2.5 | 36 | 159 | 7440402 | ||
| 74404032010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 2.2 | 3 | 33 | 138 | 7440402 | ||
| 74404041010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 2.52 | 3.35 | 41 | 142 | 7440405 | ||
| 74404042010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 3.2 | 4.8 | 27 | 120 | 7440405 | ||
| 74404052010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 3.9 | 6.3 | 19.8 | 145 | 7440405 | ||
| 74404054010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 4.9 | 8 | 12 | 187 | 7440405 | ||
| 74404063010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 5.2 | 7.5 | 10 | 130 | – | ||
| 74404064010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 5.9 | 11.5 | 11 | 159 | – | ||
| 74404084010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 6.3 | 14.1 | 8 | 127 | – | ||
| 74404043010A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 4.9 | 3.22 | 14 | 167 | – | ||
| 74404020010 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1 | 1.5 | 2 | 94 | 177 | 7440402 | ||
| 74404052012 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.2 | 3.6 | 5.2 | 23.4 | 130 | – | ||
| 74404064012 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.2 | 6.25 | 10.2 | 10 | 121 | – | ||
| 74404063012 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.2 | 4.7 | 7.3 | 12 | 106 | – | ||
| 74404024015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 1.8 | 2.2 | 65 | 104 | 7440402 | ||
| 74404032015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 2 | 2.3 | 40 | 100 | 7440402 | ||
| 74404042015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 2.95 | 4.3 | 31 | 100 | – | ||
| 74404052015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 3.3 | 4.9 | 25.7 | 92 | – | ||
| 74404054015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 4.3 | 6.9 | 15 | 137 | – | ||
| 74404063015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 4.58 | 6.6 | 13 | 98 | – | ||
| 74404064015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 6.2 | 9.7 | 12 | 115 | – | ||
| 74404084015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 5.65 | 11.4 | 10 | 95 | – | ||
| 74404020015 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.5 | 1.2 | 1.6 | 147 | 130 | 7440402 | ||
| 74404064018 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1.8 | 5.8 | 8.5 | 12 | 79 | – | ||
| 74404024022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 1.65 | 1.9 | 80 | 83 | 7440402 | ||
| 74404032022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 1.8 | 1.7 | 50 | 85 | 7440402 | ||
| 74404042022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 2.2 | 3.4 | 42 | 70 | 7440405 | ||
| 74404052022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 3 | 4.2 | 31.6 | 88 | 7440405 | ||
| 74404054022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 3.8 | 5.3 | 19 | 77 | – | ||
| 74404063022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 3.75 | 5.6 | 20 | 69 | – | ||
| 74404064022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 5.4 | 7.5 | 14 | 60 | – | ||
| 74404084022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 5.15 | 9 | 12 | 57 | – | ||
| 74404043022A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 3.83 | 2.28 | 23 | 104 | – | ||
| 74404020022 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2.2 | 0.96 | 1.4 | 225 | 107 | 7440402 | ||
| 74404024033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 1.35 | 1.5 | 120 | 66 | 7440402 | ||
| 74404032033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 1.5 | 1.5 | 70 | 72 | 7440402 | ||
| 74404041033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 1.75 | 1.8 | 69 | 78 | 7440405 | ||
| 74404042033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 2 | 2.9 | 55 | 56 | 7440405 | ||
| 74404052033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 2.6 | 3.5 | 42.2 | 70 | – | ||
| 74404054033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 3.4 | 4.3 | 24 | 48 | 7440405 | ||
| 74404063033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 3.48 | 4.5 | 25 | 59 | – | ||
| 74404064033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 4.2 | 6.5 | 21 | 42 | – | ||
| 74404084033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 4.4 | 8 | 17 | 42 | – | ||
| 74404043033A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 3.23 | 1.75 | 33 | 75 | – | ||
| 74404020033 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.3 | 0.87 | 1.1 | 275 | 78 | 7440402 | ||
| 74404052039 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3.9 | 2.4 | 2.8 | 50.5 | 59 | – | ||
| 74404024047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 1.12 | 1.2 | 173 | 52 | 7440402 | ||
| 74404032047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 1.3 | 1.2 | 96 | 56 | 7440402 | ||
| 74404041047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 1.55 | 1.3 | 91 | 60 | 7440405 | ||
| 74404042047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 1.7 | 2.2 | 70 | 48 | 7440405 | ||
| 74404052047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 2.3 | 2.7 | 55.9 | 57 | 7440405 | ||
| 74404054047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 3 | 3.8 | 30 | 43 | 7440405 | ||
| 74404063047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 3.08 | 3.3 | 30 | 50 | – | ||
| 74404064047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 3.85 | 5.5 | 26 | 36 | – | ||
| 74404084047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 4.1 | 7 | 19 | 30 | – | ||
| 74404043047A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 2.3 | 1.43 | 46 | 61 | – | ||
| 74404020047 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4.7 | 0.72 | 0.85 | 410 | 71 | 7440402 | ||
| 74404052056 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 5.6 | 2.1 | 2.55 | 67.5 | 50 | – | ||
| 74404024068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 0.85 | 1 | 300 | 40 | 7440402 | ||
| 74404032068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 1.16 | 0.94 | 120 | 45 | 7440402 | ||
| 74404042068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 1.45 | 2 | 98 | 39 | – | ||
| 74404052068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 1.9 | 2.4 | 82.7 | 43 | – | ||
| 74404054068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 2.5 | 3.2 | 43 | 35 | – | ||
| 74404063068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 2.4 | 2.8 | 47 | 40 | – | ||
| 74404064068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 3.2 | 4.3 | 31 | 27 | – | ||
| 74404084068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 3.6 | 5.5 | 24 | 27 | – | ||
| 74404020068 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6.8 | 0.55 | 0.75 | 700 | 52 | 7440402 | ||
| 74404052075 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 7.5 | 1.7 | 2.1 | 96.8 | 40 | – | ||
| 74404063082 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 8.2 | 2.25 | 2.5 | 55 | 33 | – | ||
| 74404064082 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 8.2 | 3 | 4.3 | 43 | 25 | – | ||
| 74404084082 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 8.2 | 3.45 | 5 | 26 | 25 | – | ||
| 74404024100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 0.65 | 0.8 | 430 | 30 | 7440402 | ||
| 74404032100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 0.84 | 0.87 | 230 | 37 | 7440402 | ||
| 74404041100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 1.32 | 1 | 168 | 38 | 7440405 | ||
| 74404042100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 1.2 | 1.7 | 150 | 28 | 7440405 | ||
| 74404052100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 1.6 | 1.95 | 109 | 37 | 7440405 | ||
| 74404054100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 2.1 | 2.5 | 64 | 26 | 7440405 | ||
| 74404063100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 1.95 | 2.2 | 72 | 31 | – | ||
| 74404064100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 2.85 | 3.5 | 48 | 22 | – | ||
| 74404084100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 3.3 | 4.5 | 29 | 23 | – | ||
| 74404043100A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 1.76 | 1.04 | 89 | 42 | – | ||
| 74404020100 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10 | 0.5 | 0.6 | 860 | 39 | 7440402 | ||
| 74404064120 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 12 | 2.6 | 3.3 | 58 | 21 | – | ||
| 74404084120 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 12 | 2.8 | 4.2 | 40 | 21 | – | ||
| 74404024150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 0.47 | 0.75 | 820 | 28 | 7440402 | ||
| 74404032150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 0.73 | 0.8 | 300 | 29 | 7440402 | ||
| 74404042150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 0.85 | 1.4 | 210 | 25 | – | ||
| 74404054150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 2 | 2.2 | 86 | 22 | – | ||
| 74404063150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 1.45 | 1.9 | 125 | 24 | – | ||
| 74404064150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 2.45 | 3 | 68 | 17 | – | ||
| 74404084150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 2.6 | 3.7 | 47 | 17 | – | ||
| 74404043150A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 1.45 | 0.84 | 132 | 33 | – | ||
| 74404052150 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 15 | 1.3 | 1.5 | 162 | 31 | – | ||
| 74404024180 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 18 | 0.46 | 0.65 | 830 | 26 | 7440402 | ||
| 74404064180 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 18 | 2.2 | 2.7 | 81 | 16 | – | ||
| 74404084180 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 18 | 2.4 | 3.2 | 53 | 16.5 | – | ||
| 74404024220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 0.45 | 0.55 | 910 | 22 | 7440402 | ||
| 74404032220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 0.6 | 0.6 | 450 | 25 | 7440402 | ||
| 74404042220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 0.7 | 1.1 | 290 | 23 | – | ||
| 74404052220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 1.15 | 1.35 | 225 | 22 | 7440405 | ||
| 74404054220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 1.5 | 1.7 | 129 | 17 | – | ||
| 74404063220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 1.4 | 1.6 | 140 | 21 | – | ||
| 74404064220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 2.1 | 2.5 | 89 | 15 | – | ||
| 74404084220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 2.1 | 3 | 69 | 15 | – | ||
| 74404043220A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 1.11 | 0.7 | 200 | 26 | – | ||
| 74404041220 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 22 | 0.95 | 0.64 | 380 | 22 | – | ||
| 74404024330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 0.35 | 0.45 | 1530 | 17 | 7440402 | ||
| 74404032330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 0.5 | 0.54 | 911 | 17 | 7440402 | ||
| 74404041330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 0.65 | 0.6 | 628 | 18 | 7440405 | ||
| 74404042330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 0.65 | 0.9 | 460 | 16 | 7440405 | ||
| 74404052330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 0.95 | 1.1 | 387 | 15 | 7440405 | ||
| 74404054330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 1.2 | 1.4 | 188 | 13 | 7440405 | ||
| 74404063330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 1.22 | 1.5 | 185 | 16 | – | ||
| 74404064330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 1.8 | 2 | – | 12 | – | ||
| 74404084330 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 1.8 | 2.7 | 97 | 12 | – | ||
| 74404043330A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 33 | 0.88 | 0.53 | 316 | 21 | – | ||
| 74404032470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 0.4 | 0.41 | 1050 | 15 | 7440402 | ||
| 74404041470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 0.56 | 0.55 | 987 | 17 | 7440405 | ||
| 74404042470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 0.6 | 0.7 | 620 | 11 | 7440405 | ||
| 74404052470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 0.8 | 0.95 | 521 | 13 | 7440405 | ||
| 74404054470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 1 | 1.2 | 272 | 10 | 7440405 | ||
| 74404063470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 1.06 | 1.3 | 315 | 14 | – | ||
| 74404064470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 1.4 | 1.6 | 200 | 10 | – | ||
| 74404084470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 1.55 | 2.1 | 136 | 9.8 | – | ||
| 74404043470A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 0.71 | 0.45 | 492 | 15 | – | ||
| 74404024470 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 47 | 0.33 | 0.35 | 1650 | 12 | 7440402 | ||
| 74404064560 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 56 | 1.3 | 1.5 | 220 | 8.3 | – | ||
| 74404052560 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 56 | 0.72 | 0.85 | 627 | 12 | – | ||
| 74404084560 | SPEC | 5 files | Active i| Production is active. Expected lifetime: >10 years. | 56 | 1.5 | 2 | 180 | 8 | – | ||
| 74404041680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 0.45 | 0.48 | 1495 | 13 | 7440405 | ||
| 74404052680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 0.62 | 0.8 | 769 | 9.2 | – | ||
| 74404054680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 0.8 | 0.99 | 400 | 8.7 | – | ||
| 74404063680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 0.86 | 0.88 | 360 | 11 | – | ||
| 74404064680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 1.2 | 1.4 | 289 | 7.6 | – | ||
| 74404084680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 1.25 | 1.7 | 196 | 8.1 | – | ||
| 74404042680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 0.54 | 0.63 | 840 | 9 | – | ||
| 74404024680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 0.28 | 0.3 | 2400 | 8 | – | ||
| 74404032680 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 68 | 0.34 | 0.35 | 1600 | 10 | – | ||
| 74404041101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 0.43 | 0.3 | 1697 | 10 | 7440405 | ||
| 74404052101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 0.55 | 0.6 | 1090 | 8.7 | 7440405 | ||
| 74404054101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 0.7 | 0.82 | 560 | 7.2 | 7440405 | ||
| 74404063101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 0.7 | 0.71 | 500 | 8.8 | – | ||
| 74404064101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 1 | 1.2 | 433 | 6.3 | – | ||
| 74404084101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 1.2 | 1.5 | 290 | 6.4 | – | ||
| 74404043101A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 0.49 | 0.29 | 1043 | 11 | – | ||
| 74404042101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 0.42 | 0.56 | 1430 | 8 | 7440405 | ||
| 74404032101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 0.3 | 0.26 | 1900 | 7.5 | – | ||
| 74404086101 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 100 | 1.35 | 2.15 | 238 | 4 | – | ||
| 74404064121 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 120 | 0.85 | 1 | 520 | 5.78 | – | ||
| 74404084121 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 120 | 1.15 | 1.45 | 347 | 6 | – | ||
| 74404043151A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 150 | 0.39 | 0.27 | 1634 | 9 | – | ||
| 74404042151 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 150 | 0.3 | 0.45 | 2853 | 7.5 | – | ||
| 74404064151 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 150 | 0.84 | 0.95 | 570 | 5.4 | – | ||
| 74404084151 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 150 | 0.91 | 1.25 | 478 | 5.31 | – | ||
| 74404054151 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 150 | 0.6 | 0.72 | 810 | 6.3 | – | ||
| 74404086151 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 150 | 1.2 | 1.8 | 355 | 3.2 | – | ||
| 74404043221A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 220 | 0.31 | 0.21 | 2430 | 7 | – | ||
| 74404042221 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 220 | 0.25 | 0.39 | 3450 | 5.3 | – | ||
| 74404064221 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 220 | 0.66 | 0.75 | 850 | 3.97 | – | ||
| 74404084221 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 220 | 0.81 | 1.1 | 592 | 4.5 | – | ||
| 74404054221 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 220 | 0.5 | 0.55 | 1400 | 4.5 | – | ||
| 74404086221 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 220 | 0.95 | 1.44 | 555 | 2.8 | – | ||
| 74404042331 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 330 | 0.2 | 0.3 | 5300 | 4.2 | 7440405 | ||
| 74404064331 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 330 | 0.58 | 0.65 | 1177 | 3.42 | – | ||
| 74404084331 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 330 | 0.66 | 0.9 | 865 | 3.55 | – | ||
| 74404054331 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 330 | 0.4 | 0.47 | 2100 | 3 | – | ||
| 74404086331 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 330 | 0.85 | 1.12 | 698 | 2.3 | – | ||
| 74404043471A | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 470 | 0.25 | 0.14 | 4150 | 4.7 | – | ||
| 74404054471 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 470 | 0.35 | 0.4 | 2950 | 2.5 | – | ||
| 74404086471 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 470 | 0.65 | 1.08 | 1200 | 1.8 | – | ||
| 74404054681 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 680 | 0.25 | 0.3 | 3980 | 2.3 | – | ||
| 74404063681 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 680 | 0.27 | 0.29 | 5526 | 3 | – | ||
| 74404064681 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 680 | 0.35 | 0.42 | 2650 | 1.95 | – | ||
| 74404084681 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 680 | 0.52 | 0.6 | 2032 | 2.1 | – | ||
| 74404086681 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 680 | 0.53 | 1 | 1650 | 1.6 | – | ||
| 74404054102 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1000 | 0.2 | 0.24 | 6000 | 1.9 | 7440405 | ||
| 74404063102 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1000 | 0.22 | 0.23 | 6440 | 2 | – | ||
| 74404064102 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1000 | 0.3 | 0.37 | 4783 | 1.86 | – | ||
| 74404084102 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1000 | 0.36 | 0.45 | 2870 | 2 | – | ||
| 74404086102 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1000 | 0.48 | 0.65 | 2350 | 1.39 | – | ||
| 74404086152 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 1500 | 0.36 | 0.54 | 3650 | 1.13 | – | ||
| 74404086222 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 2200 | 0.31 | 0.45 | 5000 | 0.924 | – | ||
| 74404086332 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 3300 | 0.24 | 0.36 | 7300 | 0.759 | – | ||
| 74404086472 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 4700 | 0.19 | 0.29 | 12150 | 0.62 | – | ||
| 74404086682 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 6800 | 0.14 | 0.26 | 18700 | 0.509 | – | ||
| 74404086103 | SPEC | 8 files | Active i| Production is active. Expected lifetime: >10 years. | 10000 | 0.13 | 0.2 | 22800 | 0.411 | – |
| Order Code | Datasheet | Simulation |
|---|---|---|
| 744040240016 | SPEC | |
| 744040200016 | SPEC | |
| 744040420033 | SPEC | |
| 744040200033 | SPEC | |
| 744040240047 | SPEC | |
| 744040320047 | SPEC | |
| 744040410047 | SPEC | |
| 744040520047 | SPEC | |
| 744040640047 | SPEC | |
| 744040200047 | SPEC | |
| 744040240068 | SPEC | |
| 744040640068 | SPEC | |
| 744040200068 | SPEC | |
| 744040630082 | SPEC | |
| 74404024010 | SPEC | |
| 74404032010 | SPEC | |
| 74404041010 | SPEC | |
| 74404042010 | SPEC | |
| 74404052010 | SPEC | |
| 74404054010 | SPEC | |
| 74404063010 | SPEC | |
| 74404064010 | SPEC | |
| 74404084010 | SPEC | |
| 74404043010A | SPEC | |
| 74404020010 | SPEC | |
| 74404052012 | SPEC | |
| 74404064012 | SPEC | |
| 74404063012 | SPEC | |
| 74404024015 | SPEC | |
| 74404032015 | SPEC | |
| 74404042015 | SPEC | |
| 74404052015 | SPEC | |
| 74404054015 | SPEC | |
| 74404063015 | SPEC | |
| 74404064015 | SPEC | |
| 74404084015 | SPEC | |
| 74404020015 | SPEC | |
| 74404064018 | SPEC | |
| 74404024022 | SPEC | |
| 74404032022 | SPEC | |
| 74404042022 | SPEC | |
| 74404052022 | SPEC | |
| 74404054022 | SPEC | |
| 74404063022 | SPEC | |
| 74404064022 | SPEC | |
| 74404084022 | SPEC | |
| 74404043022A | SPEC | |
| 74404020022 | SPEC | |
| 74404024033 | SPEC | |
| 74404032033 | SPEC | |
| 74404041033 | SPEC | |
| 74404042033 | SPEC | |
| 74404052033 | SPEC | |
| 74404054033 | SPEC | |
| 74404063033 | SPEC | |
| 74404064033 | SPEC | |
| 74404084033 | SPEC | |
| 74404043033A | SPEC | |
| 74404020033 | SPEC | |
| 74404052039 | SPEC | |
| 74404024047 | SPEC | |
| 74404032047 | SPEC | |
| 74404041047 | SPEC | |
| 74404042047 | SPEC | |
| 74404052047 | SPEC | |
| 74404054047 | SPEC | |
| 74404063047 | SPEC | |
| 74404064047 | SPEC | |
| 74404084047 | SPEC | |
| 74404043047A | SPEC | |
| 74404020047 | SPEC | |
| 74404052056 | SPEC | |
| 74404024068 | SPEC | |
| 74404032068 | SPEC | |
| 74404042068 | SPEC | |
| 74404052068 | SPEC | |
| 74404054068 | SPEC | |
| 74404063068 | SPEC | |
| 74404064068 | SPEC | |
| 74404084068 | SPEC | |
| 74404020068 | SPEC | |
| 74404052075 | SPEC | |
| 74404063082 | SPEC | |
| 74404064082 | SPEC | |
| 74404084082 | SPEC | |
| 74404024100 | SPEC | |
| 74404032100 | SPEC | |
| 74404041100 | SPEC | |
| 74404042100 | SPEC | |
| 74404052100 | SPEC | |
| 74404054100 | SPEC | |
| 74404063100 | SPEC | |
| 74404064100 | SPEC | |
| 74404084100 | SPEC | |
| 74404043100A | SPEC | |
| 74404020100 | SPEC | |
| 74404064120 | SPEC | |
| 74404084120 | SPEC | |
| 74404024150 | SPEC | |
| 74404032150 | SPEC | |
| 74404042150 | SPEC | |
| 74404054150 | SPEC | |
| 74404063150 | SPEC | |
| 74404064150 | SPEC | |
| 74404084150 | SPEC | |
| 74404043150A | SPEC | |
| 74404052150 | SPEC | |
| 74404024180 | SPEC | |
| 74404064180 | SPEC | |
| 74404084180 | SPEC | |
| 74404024220 | SPEC | |
| 74404032220 | SPEC | |
| 74404042220 | SPEC | |
| 74404052220 | SPEC | |
| 74404054220 | SPEC | |
| 74404063220 | SPEC | |
| 74404064220 | SPEC | |
| 74404084220 | SPEC | |
| 74404043220A | SPEC | |
| 74404041220 | SPEC | |
| 74404024330 | SPEC | |
| 74404032330 | SPEC | |
| 74404041330 | SPEC | |
| 74404042330 | SPEC | |
| 74404052330 | SPEC | |
| 74404054330 | SPEC | |
| 74404063330 | SPEC | |
| 74404064330 | SPEC | |
| 74404084330 | SPEC | |
| 74404043330A | SPEC | |
| 74404032470 | SPEC | |
| 74404041470 | SPEC | |
| 74404042470 | SPEC | |
| 74404052470 | SPEC | |
| 74404054470 | SPEC | |
| 74404063470 | SPEC | |
| 74404064470 | SPEC | |
| 74404084470 | SPEC | |
| 74404043470A | SPEC | |
| 74404024470 | SPEC | |
| 74404064560 | SPEC | |
| 74404052560 | SPEC | |
| 74404084560 | SPEC | |
| 74404041680 | SPEC | |
| 74404052680 | SPEC | |
| 74404054680 | SPEC | |
| 74404063680 | SPEC | |
| 74404064680 | SPEC | |
| 74404084680 | SPEC | |
| 74404042680 | SPEC | |
| 74404024680 | SPEC | |
| 74404032680 | SPEC | |
| 74404041101 | SPEC | |
| 74404052101 | SPEC | |
| 74404054101 | SPEC | |
| 74404063101 | SPEC | |
| 74404064101 | SPEC | |
| 74404084101 | SPEC | |
| 74404043101A | SPEC | |
| 74404042101 | SPEC | |
| 74404032101 | SPEC | |
| 74404086101 | SPEC | |
| 74404064121 | SPEC | |
| 74404084121 | SPEC | |
| 74404043151A | SPEC | |
| 74404042151 | SPEC | |
| 74404064151 | SPEC | |
| 74404084151 | SPEC | |
| 74404054151 | SPEC | |
| 74404086151 | SPEC | |
| 74404043221A | SPEC | |
| 74404042221 | SPEC | |
| 74404064221 | SPEC | |
| 74404084221 | SPEC | |
| 74404054221 | SPEC | |
| 74404086221 | SPEC | |
| 74404042331 | SPEC | |
| 74404064331 | SPEC | |
| 74404084331 | SPEC | |
| 74404054331 | SPEC | |
| 74404086331 | SPEC | |
| 74404043471A | SPEC | |
| 74404054471 | SPEC | |
| 74404086471 | SPEC | |
| 74404054681 | SPEC | |
| 74404063681 | SPEC | |
| 74404064681 | SPEC | |
| 74404084681 | SPEC | |
| 74404086681 | SPEC | |
| 74404054102 | SPEC | |
| 74404063102 | SPEC | |
| 74404064102 | SPEC | |
| 74404084102 | SPEC | |
| 74404086102 | SPEC | |
| 74404086152 | SPEC | |
| 74404086222 | SPEC | |
| 74404086332 | SPEC | |
| 74404086472 | SPEC | |
| 74404086682 | SPEC | |
| 74404086103 | SPEC |
| Samples |
|---|
| Order Code | Datasheet | Simulation | Downloads | Status | L (µH) | IR (A) | ISAT (A) | RDC (mΩ) | fres (MHz) | Design Kit | Samples |
|---|
Assortments
Articles from this product series can be found in the following assortments:
Videos
How to choose the right coil type (inductor)?!
