WE-RJ45 LAN Transformer

WE-LAN RJ45 LAN Transformer. RJ45 Connector with integrated transformer / common mode choke. Available in SMT, THT and THT with USB. Compatible to Industrial Ethernet systems like EtherCAT or Profinet.

Characteristics

  • RJ45 Connector with integrated transformer / common mode choke
  • Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s
  • Available in SMT, THT and THT with USB
  • Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEE 802.3bt
  • Improved Common Mode Rejection (CMRR) due to additional NiZn cores

Reference Designs

  • RD022 GB PoE+-Ethernet-USB“ adapter for industrial use with an EMC perspective
  • RD016 Reference Design Gigabit Ethernet Front End
  • RD041 Design of a Single Pair Ethernet System with Power over Data Lines (SPoE)

Applications

  • Suitable for industrial temperatures from –40 °C up to +85 °C
  • Compatible to Industrial Ethernet systems like EtherCAT or Profinet
  • Compliant with most IC’s for Ethernet applications such as Microchip, Broadcom, Marvell
  • Hubs, Routers, Switches, IP cameras, IoT applications

Application Notes

Products

All
10/100BASE-T
1000BASE-T
