WE-WPCC Wireless Power Transfer Transmitter Coil

Characteristics

Qi standard compliant
Litzwire used - highest Q-value available on market
Applicable for up to 15 W (up to 300 W outside the standards)
High permeability shielding
Cancels charging flux to be not coupled into sensitive components or batteries
High reliable construction
Pot core construction limits the stray field in the design
Mix and match your tool to find the perfect coil combination: Mix and Match

Applications

Portable devices used in a clean area, where connectors pose a risk of polluting e.g. medical facilities, (industrial) clean rooms, mining industry
Devices with a large number of mating cycles to avoid connector damage: e.g. Smart watches, fitness tracker...
Consumer products: e.g. Digital cameras, baby phone, remote control, smartphone sleeves, watertight products
Explosion sensitive area where the use of a physical connection is hazardous
Smart sensors
Support for your development: Use the Wireless Power 15W Kit
Which products can be offered by Würth Elektronik for Wireless Power Transmission?

Application Notes

Wireless Power Transfer Coils WE-WPCC

Wireless Power Transfer Coils WE-WPCC offer the best performance with highest Q-factor and lowest RDC values.

Product video and more information here!For customer support, please click here!
