Characteristics
- SMT multilayer chip antenna
- Extremely low profile
- Omni-directional radiation pattern
- Excellent size to performance ratio
- Smallest form factor in the industry
- Less ground clearance
- Operating temperature: -40 °C to +85°C
Applications
- Home RF/Smart home
- GSM 900
- WLAN/WiFi
- Bluetooth
- GPS/GNSS
- ZigBee
- Cellular Communication, 4G/LTE
Application Notes
Products
Order Code | Datasheet | Simulation | Downloads | Frequency Range | Gpeak (dBi) | VSWR | Frequency Range 2 | Gpeak,2 (dBi) | VSWR1 (%) | Z (Ω) | Size | Design Kit | Samples |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
7488910043 | SPEC PCN pendingDue to a pending PCN there will be a new datasheet revision issued for this order code soon. Please find the actual as well based on valid PCN date the new revision datasheet below. If you have further questions please get in contact with our sales staff. | 8 files | 423-443 MHz | -4 | 2 | – | – | – | 50 | 25 x 5 mm | – | ||
7488918022 | SPEC | 7 files | 700-960 MHz | 2.1 | 4 | 1710-2690 MHz | 5.5 | 4 | 50 | 40 x 6 mm | – | ||
7488910092 | SPEC PCN pendingDue to a pending PCN there will be a new datasheet revision issued for this order code soon. Please find the actual as well based on valid PCN date the new revision datasheet below. If you have further questions please get in contact with our sales staff. | 8 files | 868-960 MHz | -0.7 | 2.5 | – | – | – | 50 | 11 x 5.1 mm | 748001 | ||
7488910915 | SPEC | 8 files | 902-928 MHz | 0.5 | 3 | – | – | – | 50 | 5.2 x 3.7 mm | – | ||
7488920157 | SPEC | 8 files | 1550-1600 MHz | 3.4 | 2 | – | – | – | 50 | 5.2 x 3.7 mm | 748001 | ||
7488915724 | SPEC | 9 files | 1570-1580 MHz | 0.69 | 2.5 | 2400-2500 MHz | 0.97 | – | 50 | 3.2 x 1.7 mm | 748001 | ||
7488912455 | SPEC PCN pendingDue to a pending PCN there will be a new datasheet revision issued for this order code soon. Please find the actual as well based on valid PCN date the new revision datasheet below. If you have further questions please get in contact with our sales staff. | 8 files | 2400-2500 MHz | 1 | 2.2 | 4900-5875 MHz | -1.5 | 2.2 | 50 | 8.5 x 1.6 mm | 748001 | ||
7488920245 | SPEC PCN pendingDue to a pending PCN there will be a new datasheet revision issued for this order code soon. Please find the actual as well based on valid PCN date the new revision datasheet below. If you have further questions please get in contact with our sales staff. | 8 files | 2400-2500 MHz | 1.3 | 2 | – | – | – | 50 | 7.6 x 3.5 mm | – | ||
7488960245 | SPEC | 8 files | 2400-2500 MHz | 3 | 2.5 | – | – | – | 50 | 5.2 x 3.7 mm | 748001 | ||
7488922455 | SPEC | 8 files | 2400-2500 MHz | 3 | 2 | 5000-6000 MHz | 3.3 | 2 | 50 | 5.2 x 3.7 mm | 748001 | ||
74889102450 | SPEC | 8 files | 2400-2500 MHz | 3 | 2 | – | – | – | 50 | 9.0 x 2.0 mm | – | ||
74889302450 | SPEC | 8 files | 2400-2500 MHz | 0.5 | 2 | – | – | – | 50 | 3.2 x 1.6 mm | – | ||
74889502450 | SPEC | 8 files | 2400-2500 MHz | 2.5 | 2 | – | – | – | 50 | 5.2 x 2.1 mm | – | ||
74889402450 | SPEC | 8 files | 2400-2500 MHz | 2.7 | 2 | – | – | – | 50 | 7.0 x 2.0 mm | – |
