reference designRTQ6340 | Demoboard EVB_RTQ6340GQW

Overview

Topology	Buck Converter
Input voltage	8-42 V
Output 1	5 V / 0.5 A
IC revision	00

Typical applications

DCDC Converter

More information

IC product information

Products

	Order Code	Datasheet	Simulation	Downloads	Product series	L (µH)	I_RP,40K (A)	I_SAT (A)	R_{DC max.} (mΩ)	f_res (MHz)	Size	Version	Samples
	744777147	SPEC PCN pending Due to a pending PCN, a modification of the component will be implemented soon. Please find the PCN below. If you have further questions please get in contact with our sales staff. SPEC Datasheet PCN PCN document		8 files EDA models: Components ZIP ALT WE-PD (rev22g).IntLib \| 2.8 MB ZUK CadStar_WE-PD (rev20a).zip \| 36.5 KB CDS Cadence_WE-PD (rev23a).zip \| 13.3 MB EAG Eagle_WE-PD (rev23a).lbr \| 296.9 KB CAD files ZIP IGS Download_WE-PD_7345_IGS (rev1).igs \| 2.5 MB STP Download_WE-PD_7345_STP (rev1).stp \| 1.3 MB Electric models ZIP PSP PSpice_WE-PD (rev22a).zip \| 58.7 KB SCS Spectre_WE-PD (rev23a).mod \| 77.8 KB Download all 8 files as zip archive ZIP	WE-PD SMT Power Inductor	47	1.8	1.1	260	10.5	7345	Standard
